Code

Python

Our board layouts, and the checks that run on them, are written in Python.

Our work with it

8 projects that use Python.

Twelve circuit boards drawn from their design files, laid out in a grid

Twelve boards, zero design-rule errors.

Every board we have designed, checked by machine.

TRAIL OD circuit board drawn from its design file

TRAIL OD, an overdrive pedal kit.

Soft, diode-clipped drive you build yourself.

CLAW circuit board drawn from its design file

CLAW, a distortion pedal kit.

Hard clipping you build yourself.

GOLDFOOT circuit board drawn from its design file

GOLDFOOT, a transparent overdrive kit.

A clean blend keeps your own tone on top.

A pedal board with large potentiometers, drawn from its design file

Stomp 125B, a digital pedal board.

The main board of our pedal platform.

A green headphone amplifier board with a white Squatch mark, drawn from its design file

A headphone amplifier.

A small analog board with the Squatch on it.

A pedal enclosure shown exploded: lid, circuit board and base plate floating apart

An enclosure, checked before it is cut.

A pedal enclosure modelled as an object.

The input stage of a pedal schematic, drawn as a vector sheet

Schematics match their boards, 10 of 10.

Sheets drawn so a person can read them.
